Main – Sensor 640×480 pix. @ 12 µm (NETD <40 mK) – Objective lens F50 / 1.0 – Magnification x 3.5-14 (x4 zoom) – Field of view (HxV) degrees / m@100m 8.8×6.6 / 15.4×11.5 – Detection range m 2300 – Sensor – Type uncooled – Resolution pixels 640×480 – Pixel pitch um 12 – NETD mK <40 – Frame rate Hz 50 – Optics – Objective lens F50 / 1.0 – Magnification x 3.5 – 14 – Field of view (HxV) degrees / m @ 100 m 8.8×6.6 / 15.4×11.5 – Eye relief mm 14 – Display – Type AMOLED – Resolution pixels 1024×768 – Range Performance – Detection range m 2300 – Video Recorder – Video / photo resolution pixel 1024×768 – Video / photo format .mp4 / .jpg – Built-in memory GB 64 – Wi-Fi – Wireless Protocol Wi-Fi – Wireless Standard IEEE 802.11 b/g/n/ac (WPA) – Frequency GHz 2.4 / 5 – Environmental Characteristics – Degree of protection IP code (IEC60529) IP?7 (waterproof) – Operating temperature range °? -25-+40 – Connections and Compatibilities – Mount type 1/4 – Supported Application Stream Vision 2 – Power Supply – Output voltage V 3.0-4.2 – Battery type LPS 7i Li-Ion Battery Pack – Capacity mAh 6400 – Operating time on battery pack (at t=22°C) h * 8.5 – External power supply V 5V 9V (USB Type-C Power Delivery) – Weight & Size – Body material rubber armored reinforced plastic – Dimensions mm 238x72x90 – Weight kg 0.58 (w/o battery) / 0.72 (with the LPS7i battery)
