Main – Sensor 640×480 @ 12 µm (NETD <40 mK) – Objective lens F50 / 1.0 – Field of view (HxV) degrees / m@100m 8.8×6.6 / 15.4×11.5 – Detection range m 2300 – Sensor – Type uncooled – Resolution pixels 640×480 – Pixel pitch um 12 – NETD mK <40 – Frame rate Hz 50 – Optics – Objective lens F50 / 1.0 – Field of view (HxV) degrees / m @ 100 m 8.8×6.6 / 15.4×11.5 – Recommended magnification of the day sight x 2-6 – Display – Type AMOLED – Resolution pixels 1920×1080 – Range Performance – Detection range m 2300 – Video Recorder – Video / photo resolution pixel 1024×768 – Video / photo format .mp4 / .jpg – Built-in memory GB 16 – Wi-Fi – Wireless Protocol Wi-Fi – Wireless Standard IEEE 802.11 b/g/n/ac (WPA) – Frequency GHz 2.4 / 5 – Bluetooth – Wireless Protocol BLE 4.2 – Wireless Standard IEEE 802.15.1 – Frequency GHz 2.4 – Environmental Characteristics – Degree of protection IP code (IEC60529) IPX7 – Operating temperature range °? -25-+50 – Connections and Compatibilities – Max. recoil power on rifled weapon (Eo) Joules 6000 – Shock resistance on the smooth-bore rifles caliber 12 – Remote control Pulsar BT (included) – Supported Application Stream Vision 2 – Power Supply – Output voltage V 3.0-4.2 – Battery type IPS7 Li-Ion Battery Pack – Capacity mAh 6400 – Operating time on battery pack (at t=22°C) h * up to 11 – External power supply V 5V 9V (USB Type-C Power Delivery) – Weight & Size – Body material Magnesium alloy – Dimensions mm 131x78x84 – Weight kg 0.33 (w/o battery) / 0.46 (with IPS7 battery)
